- 型号/规格：-
- 品牌/商标：P+F（倍加福)
倍加福逆向反射传感器,德国p+f传感器资料
Efficient Line in a short M18 plastic housing for standard applications
Very high detection range
Retroreflective sensor with polarization filter,
M18 threaded housing design, plastic housing,
side optical face, 3.5 m detection range, red light,
light ON, AC/DC version, NPN-FET output, fixed cable
有效检测距离 0 ... 3.5 m
检测距离 4.5 m
光源类型 LED
光源类型 modulated visible red light , 640 nm
偏振滤波器 是
光斑直径 approx. 160 mm at 4.5 m
发散角 approx. 2 °
配有附件 Mounting aids
功能显示 LED yellow: lights up when receiving the light beam ;
flashes when falling short of the stability control;
OFF when light beam is interrupted
工作电压 20 ... 250 V AC/DC
输出开关类型 （显示屏）常亮
信号输出 N-channel MOSFET, short circuit protected
与标准和规范体系的一致性
产品标准 EN 60947-5-2:2007 ; IEC 60947-5-2:2007
防护等级 IP67
