minal Voltage (V) 12V minal Capacity
20hour rate (0.125A 10.50V) 2.5AH
10hour rate (0.220A 10.50V) 2.2AH
5 hour rate (0.380A 10.20V) 1.9AH
1C(2.5 to 9.6V) 1.45AH
Weight 1.1kg
Internal Resistance (at 1 KHz) 42mΩ
Maximum Discharge Current for
30 seconds: 25A
Maximum Discharge Current for
5 seconds: 37A
Operating Temperature Range
Charge 0℃(32℉) to 40℃(104℉)
Discharge -15℃(5℉) to 50℃(122℉)
Storage -15℃(5℉) to 40℃(104℉)
Charge Retention (shelf life) at 20℃(68℉)
3 month 91%
6 month 82%
12 month 64%
Charging Methods at25℃(77℉)
Cycle use:
Charging Voltage 14.4to14.9V
MaximumCharging Current0.75A
Standby use:
Float Charging Voltage 13.5to13.8V
current limit required
Life expectancy:
Cycle Use: 100% depth discharge 200cycles
80% depth discharge 225cycles
50% depth discharge 500cycles
Standby Use: 2-3 years
Case Material: ABS
Terminal: P1
Dimensions: L70*W47*100(mm)
Total Height (with terminals)106(mm)
