FY9806系列4 1/2位数字万用表技术指标 FY9806 series 41/ 2 bit dial multimeter technology index | ||
基本功能Basic Function | 量程Range | 基本Basic Accuracy
|
直流电压voltage D.C | 200mv/2v/20v/200v/1000v | &plun;（0.08%+3） |
交流电压voltage A.C | 2v/20v/200v/750v | &plun;（0.8%+3） |
直流电流Direct current | 2mA/20mA/200mA/20A | &plun;（0.8%+3） |
交流电流Alternating current | 20mA/200mA/20A | &plun;（1.0%+5） |
电阻Resistance | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ/200MΩ | &plun;（0.5%+3） |
电容Capacitance | 20nF/200nF/2uF/200uF | &plun;（3%+3） |
频率Frequency | 2KHZ | &plun;（2%+5）
|
200KHZ | ||
二管测试Diode Testing |
| √ |
三管测试Audion Testing |
| √ |
通断蜂鸣On-off buzzer |
| √ |
低电压指示Low voltage display |
| √ |
数据保持Data hold |
| √ |
自动关机Auto power off |
| √ |
功能保护Function protection |
| √ |
震保护Sampling frequency |
| √ |
电压测试输入阻The voltage measured input impedance | 10MΩ | √ |
显示值Maximum display | 1999 | √ |
电源Power supply | 9V Battery(6F22) | √ |
特点：
4 1/2位显示，测量高、新型震护套、流线型设计、手感舒适、大屏幕显示、字清晰。干扰能力强、全保护功能、高压打火电路设计。
Characteristic.
41 / 2 display, high measurement accuracy, a new te shockproof sheath, streamlined design, feel comfortable, large screen display, the character is clear.Strong anti-interference ability, complete protection function, preventing high-voltage ignition circuit design.
