(?) + 15 mm for plug removal
U : Pressure entry through any port
1 Port 1 : Pressure (NC) - Exhaust (NO)
3 Port 3 : Exhaust (NC) - Pressure (NO)
4 Connector rototable by 90° CM 10 (Pg 11P)
5 On request : exhaust port G 1/8
and protector on front sideInstant fitting connection for 4 mm OD tube
Connector rotatable by 90° CM10 (Pg 11P)
2 ? 3.5 securing holes ? 6.5 counterbored, depth: ? 3.5
Instant fitting connection for ? 6 mm OD tube
2 securing holes ? 4.5
+ 15 mm for connector removal
Left-hand pressure intake or 2 different pressure
intakes by procuring the set of two end subbases
with endpieces - code:2.
When mounted on DIN rail, it is recommended
use a securing clip on the end subbases as well
on the central subbase.
6 Optional manual override by impulse, screw or button
7 Secured by screw CM4 x 35
DIMENSIONS AND WEIGHTS
SINGLE SUBBASE-MOUNTED SOLENOID VALVE
These subbases can be directly mounted on
a symmetrical rail to EN 50022 - AFNOR NF C 63015 using 2 or more clips
(clips sold in packets or 10, code6).
(1) Equipment can be used for 2 different pressure intakes.
(2) The NC or NO function is obtained by using
a specific NC or NO solenoid valve and by reversing the position on the subbase.
