产品特点 | Feature
- n Load Cell
- n Easy installation,low center of gravity,good interchangeability.One end fixed,one end of the load.
- n Apply to car weighter,electronic scales,hopper scales.
- l 传感器
- l 安装方便、重心低、互换性好、一端固定一端加载。
- l 适用于汽车衡、电子称、料斗秤等
量程 | Capacities
0.5，1，2，3，5，10 t
技术参数 | Specification
Rated Output | 额定输出 | 2.0mv/v±1% |
Zero Balance | 点平衡 | ±1% of rated output |
Creep After 30 Minutes | 蠕变 | ±0.03% of rated output |
Nonlinearity | 非线性 | ±0.03% of rated output |
Hysteresis | 滞后 | ±0.03% of rated output |
Repeatability | 重复性 | ±0.03% of rated output |
Temp. effect on output | 灵敏度温漂 | ≤0.002% of applied output/℃ |
Temp. Effect on zero | 点温漂 | ≤0.002% of rated output/℃ |
Safe temp. Range | 可用温度范围 | -10℃ to+70℃ |
Temp.Compensated | 温度补偿范围 | -10℃ to+40℃ |
Safe Overload | 载荷 | 150% |
Input Impedance | 输入阻 | 387 Ω±20Ω |
Output Impedance | 输出阻 | 350 Ω±5Ω |
Insulation Resistance | 缘阻 | ≥5000MΩ(50V DC) |
Rated Excitation | 推荐激励电压 | 10V DC/AC |
Cable Color Code | 导线颜色 | Red(+E)Black(-E)Green(+S)White(-S) |
