| Output Rating | | 5KVAC/200mA |
|
| AC WITHSTAND VOLTAGE |
| | Range | Resolution | Accuracy |
| Output Voltage, ACV | 0 - 5000 | 10 | ±（2% of setting + 10V） |
| Output Frequency | 50Hz/60Hz ± 0.1%, User Selection |
| Output Waveform | Sine Wave ,THD.<2% (Resistive Load), Crest Factor = 1.3 - 1.5 |
| Output Regulation | ± (1% of output + 10V), From no load to full load |
| SETTINGS |
| Hi / Lo -Limit AC Current, mA | 0.00 - 99.99/100.0 - 200.0 | 0.01/0.1 | ±（2% of setting + 2counts） |
| Ramp Up Time, second | 0.1 - 999.9 | 0.1 | ±（0.1% + 0.05sec） |
| HI and LO-Limit (Real), current, mA | 0.0 - 999.9 | 0.1 |
| Dwell Time | 0, 0.3 - 999.9 sec (0=continuous) | 0.1 |
| 0, 0.1 - 999.9 min (0=continuous) | 0.1 |
| 0, 0.1 - 999.9 hr (0=continuous) | 0.1 |
| Arc Detection | 1 - 9 Ranges (9 is the most sensitivity) |
| AC Current Offset, mA | 0 - 2.000 or Auto Set |
| MEASUREMENT |
| AC Voltage, KV | 0 - 5.00 | 0.01 | ±（2% of reading + 2counts） |
| AC Current, mA | 0.00-20.00 | 0.01 | ±（2% of reading + 3counts） |
| 20.1-200.0 | 0.1 |
| GENERAL |
| Input Voltage AC | 230VAC ± 10% , 50/60Hz (Input 110V has to add Transformer Box) |
| PLC Remote Control | Input : Test , Reset , Memory1.2.3 ,Interlock |
| Output : Pass , Fail , Processing |
| External Scanner Poert | Build-in only one Scanner Port to connect 7006 Matrix Scanner. |
| Safety | Smart-GFI Function (<1mA) |
| Memory | 50 memories |
| Display | 20*2 LCD with back light |
| Key Lock | To prevent unauthorized alteration of the test Parameters |
| Calibration | Build-in software and external calibrated meters |
| Interface | RS232 (Option) |
| Alarm Volume Setting | 10 ranges set by the numeric keys on the front panel |
| Environment | 0-40℃, 20-80%RH |
| Dimension | 430mm(W)×133mm(H)×500mm(D) |
| Net Weight | 24.4Kg |
| STANDARD ACCESSORIES |
| Power Cord | ×1 |
| Fuses | ×2 (Including a spare contained in the fuse holder) |
| Interlock Disable Key (1505) | ×1 |
| Hipot Return Lead | ×1 |
| Hipot Test Lead | ×1 |
